Bahama Horizontal Panel Awning

What It Is

The Bahama Horizontal Panel Awning is a sophisticated fixed-panel shading system designed for sleek architectural integration. It delivers exceptional performance and visual refinement, particularly suited to long, narrow spaces requiring strong sun protection and aesthetic cohesion.

Category: Aluminium Awnings – Fixed Panel Series

Unique Identifiers: Three-ripple interlocking aluminium panel design, precision-engineered for strength and lightweight durability, with customisable pitch and colour options.

Primary Functions:

Provides permanent shading and weather protection.
Reduces solar heat gain and glare through windows.
Enhances architectural facades with clean, linear design.

Secondary Benefits:

Reflects up to 90% of solar radiation.
Improves building energy efficiency.
Reduces interior fading from UV exposure.

What it Does

Common Use Cases:

Residential exterior shading.
Commercial building facades.
Window and doorway protection.
Architectural detailing and enhancement zones.

Excels In:

Long, narrow installations requiring consistent panel alignment.
Mixed-use applications where aesthetics and performance are both critical.

Configurations Available:

Fixed panel design with 15° or 22° pitch options.

Typical Applications

Features and Benefits

Feature	Benefit
Three-ripple interlocking aluminium panels	Ensures strength, rigidity, and seamless appearance.
Available in 8 colours	Provides design flexibility to complement any property style.
Custom cut-outs for obstacles	Allows for clean, professional installation around pipes or fixtures.
Lightweight, corrosion-resistant aluminium	Guarantees long lifespan with minimal maintenance.
Two pitch options: 15° and 22°	Enables customisation for optimal sun control or architectural preference.
Up to 90% solar heat reflection	Significantly improves indoor comfort and energy efficiency.
Modular panel construction	Allows scalable width and corner configurations.
Simple installation process	Reduces labour time and ensures a precise finish.
Locally manufactured	Provides faster turnaround and assured quality control.

Related

Construction

Material: High-grade aluminium with interlocking horizontal panels.
Panel Design: Three-ripple height profile for strength and water run-off.
Finish: Durable powder-coated surface with 8 colour options (White, Anvil, Galaxy, Rivergum, Heritage Red, Merino, Primrose, Surfmist).
Assembly: Precision-cut, interlocking system with concealed joins.

Related

Options & Upgrades

Colours:
- Standard: White, Anvil, Galaxy, Rivergum, Heritage Red, Merino, Primrose, Surfmist.
- Highlight Colour: Panels can be configured with dual-tone combinations.
Mounting Styles:
- Standalone awning installation.
- Infill above Calypso or Seeview panels.
- Corner mitre-cut installations.
- Supported by posts or arms depending on projection.
Pitch Options:
- 15° standard.
- 22° architectural enhancement.

Related

Limitations of the Product

Size Restrictions: Custom widths available; projection depends on arm or post configuration.
Environmental Considerations: Regular cleaning required in coastal environments to maintain coating performance.
Performance Boundaries: Fixed panel design—non-retractable.
Unsuitable Applications: Not intended for cyclonic or snow-load regions without structural support.

Related

What’s the Warranty

External Installations: 5-year warranty.
Coverage Includes: Material and coating integrity.
Excludes: Impact damage, misuse, or installation outside specification.
Customer Responsibilities: Clean panels biannually and inspect joins for debris or corrosion.

Related

How It Is Measured

Measurement Points:
- Width: Overall length of awning panel.
- Projection: From wall to outer edge of panel.
Tools Required: Laser or tape measure, level.
Common Mistakes:
- Not accounting for pitch angle when calculating projection.
- Ignoring required clearance for wall brackets or posts.
Special Notes:
- Confirm any site-specific cut-outs (e.g., downpipes).

Related

How It Is Installed

Preparation: Confirm wall surface and bracket spacing.
Installation Sequence:
- Mount back channel to wall.
- Slide panels into channel.
- Secure panels in final position.
Tools & Fixings: Cordless drill, rivet gun, level, silicone sealant.
Safety: Use appropriate PPE and ladder safety protocols.
Application Notes:
- Ensure accurate pitch alignment.
- Seal all joints for water ingress prevention

Related

Compliance & Legal Requirements

Building Code: Meets NCC compliance for fixed shading structures.
Council Approvals: Not typically required for residential installations.

Related

Lead Time & Availability

Standard Lead Time: 10–15 working days.
Seasonal Variation: Up to 20 working days during peak demand.
Factors Affecting Lead Time: Custom cut-outs, corner mitres, or large-scale orders.
Quick-Ship Options: Standard colour models available within 7 working days.

Related
