Media Blinds

What It Is

Media Blinds are premium cassette roller blind systems designed to minimise light penetration and deliver a refined architectural finish.

Category: Internal Cassette Roller Blinds

System Platform: Rollease Acmeda CF90 Medium Cassette & CF dimOUT systems.

Unique Identifiers: Fully enclosed headbox, optional dimOUT side channels, direct-fix installation capability for reduced light bleed.

Primary Function: Provides enhanced light control for media rooms, bedrooms, and theatre environments.

Secondary Benefits:

  • Reduces light bleed through cassette and optional side channel integration.
  • Creates a sleek, concealed roller system aesthetic.
  • Improves thermal and glare performance when paired with blockout fabrics.
  • Supports both manual and motorised operation.

What It Does

Residential: Media rooms, bedrooms, home theatres, living spaces.
Commercial: Presentation rooms, boardrooms, education facilities.
Excels In: Spaces requiring improved blockout performance and clean architectural lines.
Configurations Available:

  • Face fit or Top fix.
  • Direct cassette fixing to ceiling or wall.
  • Optional dimOUT side channels.
  • Manual chain or motorised operation.

Typical Applications

Features and Benefits

Features Benefits
CF90 enclosed cassette Conceals tube and fabric roll for a refined finish.
Max roll capacity 77mm Suitable for larger blockout fabrics.
Direct-fix installation option Minimises light bleed without visible brackets.
Optional dimOUT side channels Improved light blockout performance.
Square or round headbox profiles Architectural flexibility.
Slimline mounting brackets Quick installation for top or face mounting.
Unique chain guide Smooth manual operation.
Available In Black, Pure White, Sandstone, Silver Grey.

Construction & Materials

  • Headbox: Aluminium cassette (Square or Round profile).
  • Mounting: Universal or Top Fix brackets; optional direct cassette fixing.
  • Max Roll Size: 77mm.
  • Controls: Chain control or motorised configuration.
  • Bottom Rail: Compatible with standard roller blind bottom rails.
  • Colour Range: Black, Pure White, Sandstone, Silver Grey.

Options & Upgrades

  • Side Channels: Optional dimOUT channels for enhanced blockout.
  • Headbox Profiles: Square or Round.
  • Mounting Options: Top fix, face fix, or direct ceiling/wall fix.
  • Motorisation: Compatible with rechargeable battery or hardwired motors.
  • Fabric Selection: Blockout fabrics recommended for media applications.

Limitations

  • Maximum Roll Diameter: 77mm (fabric dependent).
  • Blockout performance dependent on fabric choice and installation method.
  • Reveal installations may allow minor perimeter light gaps without side channels.
  • Internal use only.

Warranty

  • Warranty Term: 5-year manufacturer warranty on hardware components.
  • Coverage Includes: Manufacturing defects under normal residential or commercial use.
  • Exclusions: Fabric fading, misuse, improper installation, or impact damage.
  • Customer Responsibilities: Clean per fabric guidelines; avoid excessive force on chain systems.

How It Is Measured

  • Reveal Fit: Measure inside reveal width and drop; confirm allowance for cassette depth.
  • Face Fit: Allow overlap beyond opening for improved light blockout.
  • Side Channels: Measure precise internal dimensions to ensure correct channel alignment.
  • Tools Required: Laser measure or steel tape, spirit level.

How It Is Installed

  • Preparation: Confirm fixing substrate and ensure level mounting surface.
  • Sequence:
    • Install brackets or prepare direct-fix points.
    • Secure cassette housing.
    • Insert roller assembly.
    • Install optional side channels.
    • Set limits and test operation.

Direct-fix installation recommended for minimal light bleed.

  • Child Safety: Chain-operated systems must comply with ACCC regulations.
  • Electrical Compliance: Motorised systems must comply with Australian electrical standards.

Lead Time & Availability

  • Standard Lead Time: 10–15 working days from measure approval.
  • Seasonal Variations: May extend during peak renovation periods.
  • Extended Lead Factors: Motorisation, custom fabrics, side channel integration.
  • Quick Ship: Selected hardware colours may be available on shorter lead times.
