Kingston Vertical Panel Awning

What It Is

The Kingston Vertical Panel Awning is a high-performance fixed aluminium shading system engineered for superior solar protection and architectural refinement. Its elegant bull-nose front edge and scalloped finish complement a variety of building styles while delivering exceptional durability and environmental resistance.

Category: Aluminium Awnings – Vertical Panel Series

Unique Identifiers: 0.7mm high-grade aluminium construction with interlocked wide panels and a narrow top cover panel; configurable pitch range from 5° to 45°.

Kingston Vertical-gallery-img-8
Kingston Vertical-gallery-img-9
Kingston Vertical-gallery-img-10
Kingston Vertical-gallery-img-1
Product-feature-img
Kingston Vertical-gallery-img-2
Kingston Vertical-gallery-img-3
Kingston Vertical-gallery-img-4
Kingston Vertical-gallery-img-5
Kingston Vertical-gallery-img-7
Kingston Vertical-gallery-img-6

Primary Functions:

  • Provides permanent shading and waterproof protection.
  • Reflects up to 90% of solar radiation, reducing internal heat gain.
  • Prevents UV degradation of furnishings and interiors.

Secondary Benefits:

  • Improves building energy efficiency.
  • Extends the usability of outdoor spaces.
  • Enhances façade appearance with classic bull-nose styling.

What it Does

Common Use Cases:

  • Residential window and door coverage.
  • Patio extensions and verandas.
  • Commercial entranceways and façades.
  • Outdoor walkways or sheltered areas.

Excels In:

  • Harsh coastal environments requiring corrosion-resistant materials.
  • Buildings needing both architectural appeal and thermal control.

Configurations Available:

  • Fixed vertical panel system.
  • Adjustable pitch between 5° and 45°.
  • Standard trim or optional closed side panels.

Typical Applications

Features and Benefits

Feature Benefit
0.7mm thick aluminium construction Provides long-term durability and superior corrosion resistance compared to mild steel.
Bull-nose front edge with scalloped finish Offers timeless aesthetic appeal and classic architectural styling.
Interconnected wide panels with narrow cover panel Ensures watertight performance and enhanced structural stability.
Adjustable pitch (5°–45°) Customisable for varying site and design requirements.
Waterproof design Enables reliable all-weather protection.
Support arms up to 1500mm Allows broad projection for extended coverage.
Post supports for larger installations Delivers increased structural stability in high-exposure areas.
Comprehensive colour range Integrates seamlessly with diverse architectural palettes.
Engineered for coastal conditions Maintains finish integrity even in high-salt environments.
Locally manufactured Ensures faster lead times and consistent quality assurance.

Construction

  • Material: 0.7mm high-grade aluminium panels, corrosion-resistant and lightweight.
  • Panel Design: Wide panels interlocked with narrow cover panel for structural rigidity.
  • Edge: Bull-nose front with scalloped trim (standard).
  • Finish: Durable powder-coated surface available in a comprehensive colour range.

Options & Upgrades

  • Colours:
    • Standard: White, Anvil, Monument, Galaxy, Federation Green, Rivergum, Heritage Red, Beige, Merino, Primrose, Surfmist.
  • Side Configurations:
    • Standard open trim sides.
    • Optional closed side panels for enhanced protection.
  • Mounting Options:
    • Back channel mount on flat surface.
    • Support arms up to 1500mm.
    • Post support for extended projection.
  • Corner Design:
    • Internal or external mitre configurations available.

Limitations of the Product

  • Size Restrictions: Maximum skin length 3000mm; projections beyond 1500mm require posts.
  • Environmental Considerations: Regular cleaning in coastal areas recommended to preserve coating.
  • Performance Boundaries: Fixed panel only – non-retractable design.
  • Unsuitable Applications: Not rated for cyclonic or snow-load regions without engineering certification.

What’s the Warranty

  • External Installations: 5-year warranty.
  • Coverage Includes: Material integrity, coating performance, and corrosion resistance.
  • Excludes: Damage caused by misuse, impact, or non-compliant installation.
  • Customer Responsibilities: Clean biannually and inspect joins, arms, and posts for corrosion or wear.

How It Is Measured

  • Measurement Points:
    • Width: Overall horizontal span of panels.
    • Projection: From back channel to bull-nose edge.
  • Tools Required: Laser or tape measure, level.
  • Common Mistakes:
    • Not accounting for pitch angle when determining projection.
    • Failing to confirm back channel alignment.
  • Special Notes:
    • Verify wall flatness prior to channel installation.

How It Is Installed

  • Preparation: Confirm flat surface for back channel installation and ensure accurate pitch alignment.
  • Installation Sequence:
    • Mount back channel securely to wall.
    • Insert panels into channel.
    • Fix support arms or posts as required.
    • Install bull-nose trim and side panels if specified.
  • Tools & Fixings: Drill, rivet gun, level, silicone sealant, stainless fasteners.
  • Safety: Use PPE and adhere to height safety procedures.
  • Application Notes:
    • Ensure drainage clearance and even arm spacing.
    • Seal all joins for weatherproof integrity.

Compliance & Legal Requirements

  • Building Code: Meets NCC compliance for fixed shading structures.
  • Council Approvals: Not typically required for residential installations.

Lead Time & Availability

  • Standard Lead Time: 10–15 working days.
  • Seasonal Variation: Up to 20 working days during peak demand.
  • Factors Affecting Lead Time: Large spans, mitred corners, or colour customisation.
  • Quick-Ship Options: Standard colour configurations available within 7 working days.
